รายละเอียดสินค้า:
|
| ได้รับการรับรอง: | CE/ISO9001 | type: | High Strength and 1220,1250mm Feeding Width Glazed Tile Roll Forming Machine with 8 - 20m/min Working Speed for Roof Applications Roof panel are high strength and durableare with smooth beautiful appearance,uniform lacquer weins,so widely used in |
|---|---|---|---|
| rollers: | 10 | roller material: | No.45 steel |
| warranty: | 12 month | Weight: | 3.2T |
| Roller material: | 45# Steel, Hard Cr Plated | ||
| แสงสูง: | roof tile roll forming machine,cold roll forming machine |
||
Parameters:
| No. | Spc. | |
| 1 | suitable material | Color Steel plate, galvanized sheet |
| 2 | Feeding width | 1000mm |
| 3 | Rows of rollers | 13 rows |
| 4 | Main power | 5.5kw |
| 5 | Hydraulic power | 4kw |
| 6 | Main frame | 300 H steel |
| 7 | Thickness of raw material | 0.3-0.8mm |
| 8 | Transportation system | Chain transportation |
| 9 | Thickness of chain | 1.0inches |
| 10 | Productivity | 8-10m/min |
| 11 | Out diameter of shaft | 70mm (solid shaft) |
| 12 | Material of shaft | Material of shaft |
| 13 | Roller material | 45# steel polished and coated with chrome HRC55-60° |
| 14 | Shear mould | Gr12 |
| 15 | Voltage | 380V 50Hz 3phases |
| 16 | Control system |
PLC Frequency Control System with touch screen |
Working flow:
Decoiling the sheet — Sheet guiding — Roll forming — Measure
length Cutting the panel— panels to the supporter
Components of machine:
| Decoiler | 1set (3MT capacity) |
| Feeding & guiding device | 1set |
| Main roll forming machine | 1set |
| Hydraulic cutting system | 1set |
| Controlling system | 1set |
| Run out table | 1set |
