PLC Control Glazed Tile Roll Forming Machine / Roof Tile Roll Forming Machine For Modern Villas

ประเทศจีน PLC Control Glazed Tile Roll Forming Machine / Roof Tile Roll Forming Machine For Modern Villas ผู้ผลิต

ภาพใหญ่ :  PLC Control Glazed Tile Roll Forming Machine / Roof Tile Roll Forming Machine For Modern Villas


Place of Origin: Botou Hebei China
ชื่อแบรนด์: HC
ได้รับการรับรอง: ISO
Model Number: HC28


Minimum Order Quantity: 1set
ราคา: 12000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Contact Now
type: glazed tile roll forming machine width: 1250
thickness: 0.3-0.6mm capacity: 2-4m/min
Dimension: 7.5*1.5*1.2m life time: 10 years
Weight: 6.5T

Steel Glazed Tile Roll Forming Machine

Product Description


Machine Description Quantity Delivery time Container Type
steel glazed tile roll forming machine



45 working days

after receiving deposit


One 40GP


Glazed Tile are widely used in building: the steel-structured large-scale warehouses, plants, supermarkets,

shopping malls, trade markets, stadiums, holiday villages, sanatoriums, hotels, villas, residences, and

different kinds of greenhouses. What's more, equipment can be designed and manufactured as customers'


steel glazed tile roll forming machine Production Process:

Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Step formed→ Auto cutting

Products receiving


Parameters of tile forming machine:

Product name Glazed tile forming machine
NO. Items Parameters Remark



    Width 1000/1200/1220/1250mm Custom
    Thickness 0.40-0.70mm



Length Any length
    Length Tolerance ±2mm
3 Working Speed 25 m/min (10 piece per min as 8 feet per piece) Standard machine
4 Control System Mitsubishi/Siemens PLC& transducer Custom
5 Total Power About 12KW
6 Total Weight About 10.5T

Up to final design



1. Installation and training of corrugated roof sheet making machine:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the machine,

and also train your workers/technician face to face.

b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other n

ecessary things.

2. After Service of corrugated roof sheet making machine

a.One year guarantee for whole corrugated roof sheet making machine.

b.24 hours technical support by email or calling

c.If there is any problem found of the corrugated roof sheet making machine, we will repair it for free in

one year.



1. Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.

2. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.

3. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour), then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.

4. What can you do if the machine broken?
Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.

5. Can you be responsible for transport?
Yes,please tell me the destination port or address.we have rich experience in transport.

6. You are trade company or factory?
We are trade company but we also have own factories. Building trade company is just for exporting various types of cold roll forming machines.

7. Why your price is higher than others?
As we persist on that each factory should put quality at the first place. We spend time and money on developing How to make machines much more automatic, accurate and high quality. We can make sure thatour machine could use more than 20 years without any problem. We can provide 2 years free qualityassurance.

8. How long the machine could be made?
Normally speaking, welded pipe making machine could be made without 45 working days. If you need machines in a hurry, we can make it for you less than a month.
