Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet

Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet
Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet

ภาพใหญ่ :  Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet

รายละเอียดสินค้า:
สถานที่กำเนิด: Botou Hebei China
ชื่อแบรนด์: HC
ได้รับการรับรอง: ISO/CE
หมายเลขรุ่น: HC24/44
การชำระเงิน:
จำนวนสั่งซื้อขั้นต่ำ: 1set
ราคา: 15000-39000USD
รายละเอียดการบรรจุ: Main machine is nude,the computer control box is packed by carton box
เวลาการส่งมอบ: 30days
เงื่อนไขการชำระเงิน: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
สามารถในการผลิต: 20 sets/month

Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet

ลักษณะ
color: blue type: automatic
control system: PLC control cutting method: hydraulic cuting
per month: 30 sets
แสงสูง:

sheet metal roll forming machines

,

corrugated roll forming machine

Double Roll Forming Machine For Glazed Tile And Roof Sheet


 Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet 0Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet 1


Quick Detail:


1. Suitable to process: Color steel plate
2. Width of the plate: 1250mm
3. Rollers: 12/17 rows
4. Dimensions: 9.5*1.55*1.91m
5. Power: 4+4kw
6. Rolling material: high grade 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12
10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control



Description:


 Main parameter

No.

 Main parameter of Double Layer Roof Panel Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1250mm

3

Rollers

upper level :12 rows
Down level :17 rows

4

Dimensions

9700*1550*1910mm

5

Power

4+4kw

6

Rolling material

high grade 45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

20m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control



Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system- cutting


Application
This kind of machine make two types of tile together perfectly, it has reasonable structure, beautiful appearance, with advantage of saving space, easy operate and especially welcomed by the customer  with limit area or site
 Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet 2Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet 3
Competitive Advantage
 1. CE certification
2. noiseless
3. easy operate
4. high output
5. easy maintain

Roll Former Double Layer Roll Forming Machine For Glazed Tile Roof Sheet 4
