No Nails Roof Panel Roll Forming Machine Making Slef Locking Warehouse Roof

ข้อมูลพื้นฐาน
Place of Origin: Botou Hebei China
ชื่อแบรนด์: HC
ได้รับการรับรอง: ISO/CE
Model Number: HC350
Minimum Order Quantity: 1set
ราคา: 8000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
ข้อมูลรายละเอียด
color: as your desire type: Roofing Sheet Roll Forming Machine
control system: PLC control cutting system: hydraulic cut
per month: 30 sets workers: 100
แสงสูง:

cold roll forming machine

,

roof panel roll forming machine


รายละเอียดสินค้า

No Nails Roof Panel Roll Forming Machine Making Slef Locking Warehouse Roof

Our firm is engaged in offering a wide array of Corrugated Roof Roll Forming Machine that is widely used in construction industry for making the roof tile and wall panel outside of building. The components used for its fabrication are procured from reliable sources of the market to deliver high performance and superior quality at users end. Our offered Corrugated Roof Roll Forming Machine is highly appreciated for its outstanding functionality, sturdy construction, optimum strength, easy usage and longer functional life. We offer this machine in different specifications to fulfill the diverse needs of clients at most affordable prices.

No Nails Roof Panel Roll Forming Machine Making Slef Locking Warehouse Roof 0

Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 500mm

3. Rollers: 16 rows

4. Dimensions: 7.8*1.35*1.51m

5. Power: 3+3kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.7mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control



Description: Self-locking 500mm Roofing Sheet Roll Forming Machine For Ghana

No Nails Roof Panel Roll Forming Machine Making Slef Locking Warehouse Roof 1



Roof Sheet Roll Forming Machine  Main parameter

No.

   Main parameter of Roof Sheet Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

500mm

3

Rollers

16 rows

4

Dimensions

7800*1350*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)

7

Thickness of the plate

0.3-0.6mm

8

Productivity

8-10m/min

9

Diameter of the roller

Φ66mm

10

Voltage

380V 50Hz 3phases

11

Material of the cutting plate

Cr12

12

Hydraulic

40#

13

Processing precision

Within 1.00mm

14

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting

No Nails Roof Panel Roll Forming Machine Making Slef Locking Warehouse Roof 2

No Nails Roof Panel Roll Forming Machine Making Slef Locking Warehouse Roof 3

Intruduction:

Machine consisit of uncoiler and its base, coil sheet guilding equipment, roll forming system, cutting system, hydraulic station, controling system and supporter table.

Application:

This kind of machine make two types of tile together perfectly, it has reasonable structure, beautiful appearance, with advantage of saving space, easy operate and especially welcomed by the customer with limit area or site





This type of sheet can be widely used in plant, house, storage and simple steel roof and wall. It has advantage of pretty appearance, durable using and so on.











Competitive Advantage



1. operations safety

2. nice appearance, high quality

3. reasonable price

4. CE certification

5. ISO certification
