Color Steel Stone Coated Roof Tile Machine Line

Color Steel Stone Coated Roof Tile Machine Line
Color Steel Stone Coated Roof Tile Machine Line
Color Steel Stone Coated Roof Tile Machine Line Color Steel Stone Coated Roof Tile Machine Line Color Steel Stone Coated Roof Tile Machine Line Color Steel Stone Coated Roof Tile Machine Line Color Steel Stone Coated Roof Tile Machine Line

ภาพใหญ่ :  Color Steel Stone Coated Roof Tile Machine Line

รายละเอียดสินค้า:
สถานที่กำเนิด: ผลิตในประเทศจีน
ชื่อแบรนด์: HC
ได้รับการรับรอง: CE
หมายเลขรุ่น: HC1200
การชำระเงิน:
จำนวนสั่งซื้อขั้นต่ำ: 1 ชุด
ราคา: 45000-69000USD
รายละเอียดการบรรจุ: เครื่องหลักเป็นแบบเปลือยแผงควบคุมบรรจุด้วยกล่องกระดาษ
เวลาการส่งมอบ: 60 วันหลังจากได้รับเงินมัดจำที่ตกลงกันไว้
เงื่อนไขการชำระเงิน: เงินมัดจำ 30% โดย TT ล่วงหน้ายอดที่ต้องชำระก่อนส่งมอบ
สามารถในการผลิต: 20set / เดือน

Color Steel Stone Coated Roof Tile Machine Line

ลักษณะ
Material width: 1500 Thickness: 0.6mm
Length: 80m tech\nical support: whole life
production: 4m/min warranty: 1 year
แสงสูง:

metal roofing forming machine

,

tile forming machine

High quanlity colorful stone coated steel roofing tile machine stone coated roof tile production line



Machine technical parameter

1.materialmaterial thickness:0.4-0.6mm galvanized sheet is better

2.work process:feeding-first spraying glue-blasting stone-first drying-second spray glue-second drying-production

3.workers to operate:6 workers can hand with this machine

4.sales area:global

5.advantage no sounds, good looking, high quality

6.productivity 6pieces/min

7.main work unit : spraying unit, blasting unit, drying unit, second spraying unit and second drying unit.





Technical characteristic:

1.Resist to artificial climate aging:100h film no crack,no powder,no bubbles,no obvious discoloration.

2.Heat resistant:90±2°c no obvious change.

3.Low temperature resistant:-40±2°c·24h no obvious change.

4.Waterproof:240h no bubbles,no obvious change.

Color Steel Stone Coated Roof Tile Machine Line 0

1. Automatic bottom glue spraying equipment.

outside dimension:4000*1350*850mm.

structure:channel steel,welded.

transmission:2.2kw variable-frquency adjustable-speed motor 0-32 r/min.

conveying device:reciprocating chain conveys.

automatic glue spraying assembly:with motor:0.06kw

adsorption of dust removal equipment:1 set.

air compressor:1 set 0.9m3

automatic pressure glue canister:1 set range of adjustable pressure:0.1-0.6MPa.

automatic glue spraying gun:4 sets.

fill glue gun:5 sets.

glue gun stand: 1 set.

Color Steel Stone Coated Roof Tile Machine Line 1

2 automatic sandblasting room

outside dimension:3000*1850*700mm.

structure:channel steel,angle steel,welded.

transmission:with glue spraying equipment compound chain transmit.

convey device:compound chain transmit.

automatic sand hopper:1 set dimension:550*600*500mm.

automatic rising machine:1 set.rising height:1.9m power:300kg/h.

sand-blasting gun:4 sets.

Color Steel Stone Coated Roof Tile Machine Line 2



3 first drying room

outside dimension:25000*800*1200mm.

structure:carbon steel welded.

frame type heat presservation wall:fill up with heat preservation material which is bended with 1mm carbon steel.

automatic temperature controller: 2 sets,range od adjustable temperature:0-160º.

infrared fluorescent tube:50 pcs.

conveying device:reciprocating chain conveys.

cooling device:1 set.

Color Steel Stone Coated Roof Tile Machine Line 3



4 automatic surface glue spraying equipment

outside dimension:3000*850*700.

structure:carbon steel welded.

automatic glue spraying gun:2 sets.

automatic spraying assembly:1 set range of pressure:0.1-0.6 MPa.

adsorption of dust removal equipment :1 set.

manual spraying gun:5 sets.

Color Steel Stone Coated Roof Tile Machine Line 4



5 second drying room equipment

outside dimension:30000*850*700mm.

structure: carbon steel welded.

frame type heat presservation wall:30m. fill up with heat preservation material which is bended with 1mm carbon steel.

conveying device:reciprocating chain conveys.

infrared heat tube:50 pcs.

automatic temperature controller:2 sets range of adjustable temperature:0-160°

conveying device:reciprocating connection conveys 30m.

cooling device:1 set.

automatic printing code and marketing:1 set of automatic printer.

total equipment matches total control station 1 set(control system)

producing :3-6m/min calculate as 1.2m per piece.eight hours,produce 1500 prc every day.

whole machine power:113kw


Color Steel Stone Coated Roof Tile Machine Line 5





1.Warranty time:one year,and we will provide the technical support for the whole life.

2.What's more,one year for free,after the warranty period .we will help you repair the machine,you only responsible for the labour and parts,when the machine have some problem.
